Building a Legacy of Drilling Innovation
Stoneham Drilling Corporation provides contract drilling services within the United States. Our fleet currently consists of 3 advanced Efficient Long Reach (“ELR”) 1500 HP AC triple drilling rigs.
Stoneham has designed safe, efficient and highly versatile rigs. These drilling rigs can include features such as walking systems, 7500 psi circulating system, AC power, top drive, automated pipe handling, automated catwalk, floor robot, hydraulic substructure leveling, hydraulic BOP handling and Range III tubulars.
Rig Specifications
| RIGS | ||||
|---|---|---|---|---|
| Specification | Rig 16 | Rig 17 | Rig 18 | |
| Type | AC Pad Trpl | AC Pad Trpl | AC Pad Trpl | |
| TVD (ft) | 18,000 | 18,000 | 18,000 | |
| Drawbacks Model | TSM 1500 AC | TSM 1500 AC | TSM 1500 AC | |
| Drawworks Rating (Hp) | 1,500 | 1,500 | 1,500 | |
| Top Drive Model | Canrig 1035AC | Canrig 1035AC | Canrig 1035AC | |
| Iron Roughneck | NOV ST-80 | NOV ST-80 | NOV ST-80 | |
| Static Hook Load (lb) | 650,000 | 650,000 | 650,000 | |
| Setback (lb) | 400,000 | 400,000 | 400,000 | |
| Circulating System (psi) | 7,500 | 7,500 | 7,500 | |
| Pump #1 | Gardner Denver PZ-11 | Gardner Denver PZ-11 | Gardner Denver PZ-11 | |
| Pump #1 Rating (Hp) | 1,600 | 1,600 | 1,600 | |
| Pump #2 | Gardner Denver PZ-11 | Gardner Denver PZ-11 | Gardner Denver PZ-11 | |
| Pump #2 Rating (Hp) | 1,600 | 1,600 | 1,600 | |
| Pump #3 | Gardner Denver PZ-11 | Gardner Denver PZ-11 | ||
| Pump #3 Rating (Hp) | 1,600 | 1,600 | ||
| Loads | 62 | 62 | 62 | |
| Omnidirectional Walking / Skidding | Omnidirectional Walking | Omnidirectional Walking | Omnidirectional Walking | |
| Location | Powder River Basin | Williston Basin | Williston Basin | |
